Pressure seal bonnet, port outside screw and yoke (OS&Y)
Threaded, butt-welded or socket welded ends; design BS53522
Specification (NPS)
F.P
1/2
3/4
1
1 ¼
1 ½
2
2 ½
Face to face
L
110
110
150
150
210
235
Handwheel diameter
W
110
110
130
210
180
250
Height
H
227
227
300
307
40
448
Flow prot dimenstion
d
9
12
15
20
32
40
Weight (kg)
5
5
10
11.5
22
37
CL900-CL1500
Pressure seal bonnet, port outside screw and yoke (OS&Y)
Threaded, butt-welded or socket welded ends; design BS53522
Specification (NPS)
F.P
1/2
3/4
1
1 ¼
1 ½
2
2 ½
Face to face
L
140
140
140
178
178
216
Handwheel diameter
W
200
200
200
280
280
300
Height
H
320
320
320
440
440
490
Flow prot dimenstion
d
12
15
20
28
32
40
Weight (kg)
11.5
10.8
10.5
19.6
21.1
55.4
CL2500
Bolted bonnet, full port outside screw and yoke (OS&Y)
Socket welded ends; design conform to ASME B16.34
Specification (NPS)
F.P
1/2
3/4
1
1 ¼
1 ½
2
2 ½
Face to face
L
150
150
210
235
235
Handwheel diameter
W
130
130
250
300
300
Height
H
293
300
390
435
435
Flow prot dimenstion
d
11
14
19
28
35
Weight (kg)
10
10.3
22.4
38
38
CL2500
Pressure seal bonnet, full port outside screw and yoke (OS&Y)
Socket welded ends; design conform to ASME B16.34
Specification (NPS)
F.P
1/2
3/4
1
1 ¼
1 ½
2
2 ½
Face to face
L
186
186
186
232
232
279
Handwheel diameter
W
200
200
200
280
280
300
Height
H
375
378
380
490
490
540
Flow prot dimenstion
d
11
14
19
25
28
35
Weight (kg)
12.3
11.6
10.8
26.0
28.4
60
