Phụ kiện đường ống inox vi sinh HONTO (9)

Dimension/Kích thước (mm)

Size/Cỡ

A

B

C

D

E

14WI I-LINE Ferrule No.36-54

Đầu nối hàn clamp inox vi sinh 14WI I-LINE

1.0”

1.5”

2”

2.5”

3.0”

4.0”

25.65

38.35

51.05

63.75

76.45

101.85

22.1

34.8

47.5

60.2

72.89

97.38

31.5

44.2

56.9

69.6

83.82

109.14

50.67

50.67

67.05

84.

98.3

123.7

19.84

23.8

26.19

26.36

30.94

34.11

Size/Cỡ

A

B

L

NPT

22MP Female Adapter No 36-55

Đầu nối hàn clamp inox vi sinh 22MP

1.0”&1.5”*1/4”

1.0”&1.5”*3/8”

1.0”&1.5”*1/2”

1.0”&1.5”*3/4”

1.0”&1.5”*1”

2.0*1.0”

2.0*1.5”

2.5*1.0”

2.5*1.5”

2.5*2.0”

3.0*1.0”

3.0*1.5”

3.0*2.0”

4.0*1.0”

4.0*1.5”

4.0*2.0”

4.0*2.5”

4.0*3.0

38.1

38.1

38.1

38.1

38.1

50.8

50.8

63.5

63.5

63.5

76.2

76.2

76.2

101.6

110.6

101.6

101.6

101.6

50.5

50.5

50.5

50.5

50.5

64.0

64.0

77.5

77.5

77.5

91

91

91

119

119

119

119

119

19

19

19

19

19

19

19

35

35

35

35

35

35

35

35

35

35

35

1/4”NPT

  3/8”NPT

1/2”NPT

3/4”NPT

1”NPT

1.0”NPT

1.5”NPT

1.0”NPT

1.5”NPT

2.0”NPT

1.0”NPT

1.5”NPT

2.0”NPT

1.0”NPT

1.5”NPT

2.0”NPT

2.5”NPT

3.0”NPT

Size/Cỡ

A

B

C

D

E

E1

Hose 14MPHR No.36-56

Đuôi chuột ống mềm nối clamp 14MPHR

½”

¾”

1.0”

1.5”

2.0”

2.5”

3.0”

4.0”

50.5

50.5

50.5

50.5

64

77.5

91

119

34.5

34.5

34.5

34.5

46

60.3

73

97.6

9.5

15.8

20.6

33.2

46

58.7

72

97.6

13.7

21.4

25.4

38.1

50.8

63.5

76.2

101.6

38

38

43

43

58.7

59.5

78.6

85.5

140

140

140

140

140

140

140

140
