Phụ kiện đường ống inox vi sinh HONTO (30)

Dimension/Kích thước (mm)

Size/Cỡ

L1

D

Clamped Tee BS4825 No.57-131

Tê inox vi sinh BS4825 nối clamp

1/2”

3/4”

1”

1^1/2”

2”

2^1/2”

3”

4”

57.2

60.3

66.7

73

85.7

92.1

98.4

120.7

25.4

25.4

50.5

50.5

64

77.5

91

119

Size/Cỡ

L1

D

Welded Cross BS4825 No.56-132

Chữ thập inox vi sinh BS4825 nối hàn

1”

1^1/2”

2”

2^1/2”

3”

4”

65

85

110

135

155

195

25.4

38.1

50.8

63.5

76.2

101.6

Size/Cỡ

A

D

d

Welded Reducer BPE No.57-133

Côn thu bầu giảm inox vi sinh BPE nối hàn

1*0.75

1.5*0.75

1.5*1.0

2.0*1.0

2.0*1.5

2.5*1.5

2.5*2.0

3.0*1.5

3.0*2.0

3.0*2.5

4.0*2.0

4.0*2.5

4.0*3.0

6.0*4.0

101.6

127

127

184.2

133.4

184.6

139.7

235

190.5

139.7

298.5

247.7

196.9

254

25.4

38.1

38.1

50.8

50.8

63.5

63.5

76.2

76.2

76.2

101.6

101.6

101.6

152.4

19.1

19.1

25.4

25.4

38.1

38.1

50.8

38.1

50.8

63.5

50.8

63.5

76.2

101.6
