Phụ kiện đường ống inox vi sinh HONTO (10)

DIN 16AMP

3A-16AMP

ISO-16AMP

Size/Cỡ

A

B

Size/Cỡ

A

B

Size/Cỡ

A

B

Blank N0.37-57

Nắp bịt clamp inox vi sinh

½”

¾”

1.0”

1.5”

2.0”

2.5”

3.0”

4.0”

10

20

80

25

25

50.5

50.5

64

77.5

91

119

34

34

106

6.4

6.4

6.4

6.4

6.4

6.4

6.4

7.9

6.4

6.4

6.4

A37

1/2”-3/4”

1.0”-1.5”

2.0”

2.2”

3.0”

4.0”

6”

8”

10”

12”

34

25.2

50.5

61

77.5

91

119

166.8

217.7

268.5

319.3

6.3

5

6.3

6.3

6.3

6.3

7.9

11.1

11.1

11.1

11.1

DN20

DN25

DN32

DN40

DN50

DN65

DN80

DN100

DN125

DN150

DN200

50.5

50.5

50.5

61

77.5

91

106

130

155

183

233.5

6.3

6.3

6.3

6.3

6.3

6.3

6.3

7.9

7.9

11.1

11.1

Size/Cỡ

A

B

Ferrule Gasket (Epdm, silicon,viton, Ptfe) Flange Type 13Fg  N0.37-58

Gioăng đầu nối clamp (EPDM, SILICON, VITON, PTFE) 13Fg (1)

1.0”

1.5”

2.0”

2.5”

3.0”

4.0”

6.0”

10”

12”

22.8

35.8

48.8

60.5

73.1

97.8

148

249

300

52.7

52.7

66.2

79.7

93.2

121.2

169.1

270.7

321.5

Size/Cỡ

A

B

Ferrule Gasket (Epdm, silicon,viton, Ptfe) Flange Type 13Fg  N0.37-59

Gioăng đầu nối clamp (EPDM, SILICON, VITON, PTFE) 13Fg (2)

½”

¾”

1.0”

1.5”

2.0”

2.5”

3.0”

4.0”

6.0”

8.0”

21.8

21.8

50

50

63.5

76.2

88.9

118

165

216

9.9

16.3

22.7

35.9

48.6

61.3

74

98.6

147.6

196.6
