Nồi hấp thanh trùng inox vi sinh dạng đôi kiểu quay 2

D. Pressure and temperature digitally displayed

E. All the processing being recorded to the disks.

F. There are various sterilization modes pre stored for choices, to a maximum of 250 sterilization formulas.

G. The Retort adopts the analog temperature controlled system, you can set multi period heating mode.

According to different requirements of different food products, you can set different heating and cooling procedures, as well as use the multi period heating sterilization mode and twice cooling mode.

H. F value measuring function

Each set of water bath Retort could be equipped with the F value measuring function. The F value software will calculate F valve every 3s. Being treated by the data processing software, all the sterilization data, including sterilization condition, F value, time-temperature chart and time-pressure chart will be saved or printed, which offers convenience to production management.

6. The rotary Retort adopts the pneumatic pressed sets, guaranteeing the safety of food product as well as maintaining the equipment’s function.

Note: "*"means it is optional

Items Danh mục

Units Đơn vị

Specification Thông số kỹ thuật

Diameter of vessel body

Đường kính tank thanh trùng

mm

F1300

F1500

Number of baskets

Số lượng rổ

­/pcs

4

4

Maximum working pressure

Áp lực làm việc cao nhât

Mpa

0.35

0.35

Maximum working temperature

Nhiệt độ làm việc lớn nhất

°C

137

137

Revolving velocity

Vận tốc quay

r/min

3-8

3-8

Steam pressure

Áp suất hơi nước

Mpa

0.6

0.6

Steam consumption

Tiêu thụ hơi nước

Kg/(cycle)

300

380

Cooling water pressure

Áp suất nước làm mát

Mpa

0.3

0.3

Consumption of cooling water

Tiêu thụ nước làm mát

m3/(cycle)

5~10

8~12

Compressed air consumption

Tiêu thụ khí nén

m3/min

0.6~1.0

0.8~12

Electrical capacity

Công suất điện

KW

13

15

Dimension

Kích thước bên ngoài

L´w´h(mm)

5600×2100×3700

5600×2200×4100
